TRIGON SUPER NOVO

Imagine technology

The new TRIGON Super Novo 3D Mondolfo Ferro wheel aligner with 2-camera reading system is fast, accurate and reliable. The software is intuitive and user-friendly for fast and accurate wheel alignment measurements.

The wheel aligner is compatible with the new universal

Display of values up to 0.01°
Sensor holder from 10” to 22”, 26” with adapter.
Measurement “in difference” to eliminate measurement problems in critical sunlight conditions or in the presence of light reflections.
Intuitive two-key operation
User-friendly software with easily accessible tutorial
PC with multilingual Windows 10 IoT operating system
Easy access to all setting values
Steering automatic measurements directly from the targets
Chassis measurement data
Factory-calibrated, calibration checked only upon installation, no periodic calibrations required
User database for entering or changing vehicle data
Customer database, for specific activities, to recall and save all customer data.
Assistance system to drive the vehicle on the lift by means of a remote camera (optional)
Convenient side trolley for clamp and sensor holder (optional)
Mobile camera to work from the ground level up to a height of 2 meters (optional)

Technical data

Total toe	± 20 °
Half toe	± 10 °
Camber	± 10 °
Caster	± 30 °
King pin	± 30 °
Set back	± 22 °
Thrust angle	± 10 °
Steering difference at	± 20 °

HIGH-RESOLUTION LIGHT TARGET

It can be detached from the bracket and is compatible with all MONDOLFO FERRO brackets.
Front infrared filter for enhanced immunity to solar reflections.

SUPERIOR QUALITY CAMERA
Latest generation high-resolution HI-Q camera for artificial vision.
Low distortion optimised monolithic lens (RAVG < 0.50% in NIR) with anti-reflection nano coating. Integrated LPF filter to eliminate sunlight reflections.

MEASUREMENT IN DIFFERENCE
Each acquisition is differentially processed by 2 consecutive images to eliminate measurement problems in critical sunlight conditions or in the presence of light reflections.
Operating light indications thanks to the integrated synoptic panel.
